دیتاشیت FDB045AN08A0
مشخصات دیتاشیت
| نام دیتاشیت |
FDB045AN08A0
|
| حجم فایل |
982.991
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
12
|
مشخصات
-
Manufacturer:
ON Semiconductor
-
Series:
PowerTrench®
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
FET Type:
N-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
75V
-
Current - Continuous Drain (Id) @ 25°C:
19A (Ta), 90A (Tc)
-
Drive Voltage (Max Rds On, Min Rds On):
6V, 10V
-
Rds On (Max) @ Id, Vgs:
4.5mOhm @ 80A, 10V
-
Vgs(th) (Max) @ Id:
4V @ 250µA
-
Gate Charge (Qg) (Max) @ Vgs:
138nC @ 10V
-
Vgs (Max):
±20V
-
Input Capacitance (Ciss) (Max) @ Vds:
6600pF @ 25V
-
FET Feature:
-
-
Power Dissipation (Max):
310W (Tc)
-
Operating Temperature:
-55°C ~ 175°C (TJ)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
D²PAK
-
Package / Case:
TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
-
Base Part Number:
FDB045
-
detail:
N-Channel 75V 19A (Ta), 90A (Tc) 310W (Tc) Surface Mount D²PAK
