RHRP30120-F102 数据手册
其他文档
未找到其他文档！
技术规格
- Manufacturer: ON Semiconductor
- Series: -
- Packaging: Tube
- Part Status: Active
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 1200V
- Current - Average Rectified (Io): 30A
- Voltage - Forward (Vf) (Max) @ If: 3.2V @ 30A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 85ns
- Current - Reverse Leakage @ Vr: 250µA @ 1200V
- Capacitance @ Vr, F: -
- Mounting Type: Through Hole
- Package / Case: TO-220-2
- Supplier Device Package: TO-220-2
- Operating Temperature - Junction: -65°C ~ 175°C
- Base Part Number: RHRP30
- detail: Diode Standard 1200V 30A Through Hole TO-220-2
