BFL4026-1E دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
BFL4026-1E
|
|
حجم فایل
|
58.062
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
7
|
مشخصات فنی
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
onsemi BFL4026-1E
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Power Dissipation (Pd):
2W;35W
-
Total Gate Charge (Qg@Vgs):
33nC@10V
-
Drain Source Voltage (Vdss):
900V
-
Input Capacitance (Ciss@Vds):
650pF@30V
-
Continuous Drain Current (Id):
3.5A
-
Gate Threshold Voltage (Vgs(th)@Id):
-
-
Reverse Transfer Capacitance (Crss@Vds):
-
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
3.6Ω@2.5A,10V
-
Package:
TO-220
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Bulk
-
Part Status:
Obsolete
-
FET Type:
N-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
900V
-
Current - Continuous Drain (Id) @ 25°C:
3.5A (Ta)
-
Drive Voltage (Max Rds On, Min Rds On):
10V
-
Rds On (Max) @ Id, Vgs:
3.6Ohm @ 2.5A, 10V
-
Vgs(th) (Max) @ Id:
-
-
Gate Charge (Qg) (Max) @ Vgs:
33nC @ 10V
-
Vgs (Max):
±30V
-
Input Capacitance (Ciss) (Max) @ Vds:
650pF @ 30V
-
FET Feature:
-
-
Power Dissipation (Max):
2W (Ta), 35W (Tc)
-
Mounting Type:
Through Hole
-
Supplier Device Package:
TO-220FI(LS)
-
Package / Case:
TO-220-3 Full Pack
-
Base Part Number:
BFL40
-
detail:
N-Channel 900V 3.5A (Ta) 2W (Ta), 35W (Tc) Through Hole TO-220FI(LS)
