FGAF40N60SMD دیتاشیت

FGAF40N60SMD

مشخصات دیتاشیت

نام دیتاشیت FGAF40N60SMD
حجم فایل 994.898 کیلوبایت
نوع فایل pdf
تعداد صفحات 10

مشاهده دیتاشیت FGAF40N60SMD

دانلود دیتاشیت

سایر مستندات

FGAF40N60SMD 11 pages

مشخصات فنی

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • IGBT Type: Field Stop
  • Voltage - Collector Emitter Breakdown (Max): 600V
  • Current - Collector (Ic) (Max): 80A
  • Current - Collector Pulsed (Icm): 120A
  • Vce(on) (Max) @ Vge, Ic: 1.9V @ 15V, 40A
  • Power - Max: 115W
  • Switching Energy: 870µJ (on), 260µJ (off)
  • Input Type: Standard
  • Gate Charge: 119nC
  • Td (on/off) @ 25°C: 12ns/92ns
  • Test Condition: 400V, 40A, 6Ohm, 15V
  • Reverse Recovery Time (trr): 36ns
  • Operating Temperature: -55°C ~ 175°C (TJ)
  • Mounting Type: Through Hole
  • Package / Case: TO-3P-3 Full Pack
  • Supplier Device Package: TO-3PF
  • Base Part Number: FGAF4
  • detail: IGBT Field Stop 600V 80A 115W Through Hole TO-3PF
