- Datasheet STK681-360-E
STK681-360-E Datasheet
Datasheet specifications
| Datasheet's name | STK681-360-E |
|---|---|
| File size | 341.279 KB |
| File type | |
| Number of pages | 12 |
Download Datasheet STK681-360-E |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- RoHS: true
- Type: Brush DC Motor
- Category: Power Supply Chip/Motor Driver ICs
- Interface: Parallel
- Output Current: 4.5A
- Supply Voltage: 4.75V~5.25V
- Operating Temperature: 0°C~+105°C@(Tc)
- Package: SIP-19
- Manufacturer: onsemi
- Series: -
- Packaging: Tube
- Part Status: Active
- Motor Type - Stepper: -
- Motor Type - AC, DC: Brushed DC
- Function: Driver - Fully Integrated, Control and Power Stage
- Output Configuration: Half Bridge (2)
- Technology: Power MOSFET
- Step Resolution: -
- Applications: General Purpose
- Current - Output: 4.5A
- Voltage - Supply: 4.75V ~ 5.25V
- Voltage - Load: 10V ~ 30V
- Mounting Type: Through Hole
- Package / Case: 19-SSIP Formed Leads
- Supplier Device Package: 19-SIP
- Base Part Number: STK681
- detail: Motor Driver Power MOSFET Parallel 19-SIP
