دیتاشیت FQP3N50C-F080

FQP3N50C, FQPF3N50C

مشخصات دیتاشیت

نام دیتاشیت FQP3N50C, FQPF3N50C
حجم فایل 1000.17 کیلوبایت
نوع فایل pdf
تعداد صفحات 10

دانلود دیتاشیت FQP3N50C, FQPF3N50C

FQP3N50C, FQPF3N50C Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 500V
  • Current - Continuous Drain (Id) @ 25°C: 1.8A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 2.5Ohm @ 1.5A, 10V
  • Vgs(th) (Max) @ Id: 4V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 13nC @ 10V
  • Vgs (Max): ±30V
  • Input Capacitance (Ciss) (Max) @ Vds: 365pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 62W (Tc)
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Through Hole
  • Supplier Device Package: TO-220-3
  • Package / Case: TO-220-3
  • Base Part Number: FQP3
  • detail: N-Channel 500V 1.8A (Tc) 62W (Tc) Through Hole TO-220-3
