LM2931, NCV2931 Series Datasheet

LM2931, NCV2931 Series

Datasheet specifications

Datasheet's name LM2931, NCV2931 Series
File size 565.711 KB
File type pdf
Number of pages 23

Download Datasheet LM2931, NCV2931 Series

Download Datasheet

Other documentations

LM2931AT-5.0G 28 pages

Technical specifications

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: onsemi LM2931ACTVG
  • Output Type: Adjustable
  • Output Current: 100mA
  • Output Voltage: 2.7V~29.5V
  • Dropout Voltage: 0.6V@(100mA)
  • Output Polarity: positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 26V
  • Operating Temperature: -40°C~+125°C
  • Quiescent Current (Ground Current): 1mA
  • Package: TO-220-5
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • Output Configuration: Positive
  • Number of Regulators: 1
  • Voltage - Input (Max): 40V
  • Voltage - Output (Min/Fixed): 2.7V
  • Voltage - Output (Max): 29.5V
  • Voltage Dropout (Max): 0.6V @ 100mA
  • Current - Output: 100mA
  • PSRR: -
  • Control Features: -
  • Protection Features: Over Current, Over Temperature
  • Mounting Type: Through Hole
  • Package / Case: TO-220-5 Formed Leads
  • Supplier Device Package: TO-220-5
  • Base Part Number: LM2931
  • detail: Linear Voltage Regulator IC 1 Output 100mA TO-220-5
