RHRP1540, RHRP1560 Datasheet

RHRP1540, RHRP1560

Datasheet specifications

Datasheet's name RHRP1540, RHRP1560
File size 634.72 KB
File type pdf
Number of pages 5

Download Datasheet RHRP1540, RHRP1560

Download Datasheet

Other documentations

RHRP1560 6 pages

Technical specifications

  • RoHS: true
  • Category: Diodes/Bridge Rectifiers
  • Datasheet: onsemi RHRP1560-F102
  • Package: TO-220-2
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 600V
  • Current - Average Rectified (Io): 15A
  • Voltage - Forward (Vf) (Max) @ If: 2.1V @ 15A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Reverse Recovery Time (trr): 40ns
  • Current - Reverse Leakage @ Vr: 100µA @ 600V
  • Capacitance @ Vr, F: -
  • Mounting Type: Through Hole
  • Package / Case: TO-220-2
  • Supplier Device Package: TO-220-2
  • Operating Temperature - Junction: -65°C ~ 175°C
  • Base Part Number: RHRP15
  • detail: Diode Standard 600V 15A Through Hole TO-220-2
