دیتاشیت NC7SZ02L6X
مشخصات دیتاشیت
| نام دیتاشیت |
NC7SZ02
|
| حجم فایل |
252.102
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
11
|
مشخصات
-
RoHS:
true
-
Series:
7SZ
-
Category:
Logic ICs/Gates
-
Datasheet:
onsemi NC7SZ02L6X
-
Sink Current:
32mA
-
Source Current:
32mA
-
Supply Voltage:
1.65V~5.5V
-
Logic Gate Type:
NORGate
-
Number of Channels:
1
-
Operating Temperature:
-40°C~+85°C
-
Propagation Delay Time:
4.3ns@5V,50pF
-
Quiescent Current (Max):
2uA
-
Package:
MicroPak-6
-
Manufacturer:
onsemi
-
Packaging:
Cut Tape (CT)
-
Part Status:
Discontinued at Digi-Key
-
Logic Type:
NOR Gate
-
Number of Circuits:
1
-
Number of Inputs:
2
-
Features:
-
-
Voltage - Supply:
1.65V ~ 5.5V
-
Current - Quiescent (Max):
2µA
-
Current - Output High, Low:
32mA, 32mA
-
Logic Level - Low:
-
-
Logic Level - High:
-
-
Max Propagation Delay @ V, Max CL:
4.3ns @ 5V, 50pF
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
6-MicroPak
-
Package / Case:
6-UFDFN
-
Base Part Number:
NC7SZ0
-
detail:
NOR Gate IC 1 Channel 6-MicroPak
