دیتاشیت MC74HC4052ADWR2G

MC74HC4052ADWR2G

مشخصات دیتاشیت

نام دیتاشیت MC74HC4052ADWR2G
حجم فایل 94.603 کیلوبایت
نوع فایل pdf
تعداد صفحات 18

MC74HC4052ADWR2G

دانلود دیتاشیت

سایر مستندات

MC74HC4051A, 52A, 53A 17 pages

مشخصات فنی

  • RoHS: true
  • Category: Logic ICs/Signal Switches / Encoders & Decoders / Multiplexers
  • Datasheet: onsemi MC74HC4052ADWR2G
  • Package: SOIC-16-300mil
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Switch Circuit: SP4T
  • Multiplexer/Demultiplexer Circuit: 4:1
  • Number of Circuits: 2
  • On-State Resistance (Max): 100Ohm
  • Channel-to-Channel Matching (ΔRon): 10Ohm
  • Voltage - Supply, Single (V+): 2V ~ 6V
  • Voltage - Supply, Dual (V±): ±2V ~ 6V
  • Switch Time (Ton, Toff) (Max): -
  • -3db Bandwidth: 95MHz
  • Charge Injection: -
  • Channel Capacitance (CS(off), CD(off)): 80pF
  • Current - Leakage (IS(off)) (Max): 100nA
  • Crosstalk: -60dB @ 1MHz
  • Operating Temperature: -55°C ~ 125°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 16-SOIC (0.295", 7.50mm Width)
  • Supplier Device Package: 16-SOIC
  • Base Part Number: MC74HC4052
  • detail: 2 Circuit IC Switch 4:1 100Ohm 16-SOIC
