NLU1GT86MUTCG دیتاشیت

NLU1GT86MUTCG

مشخصات دیتاشیت

نام دیتاشیت NLU1GT86MUTCG
حجم فایل 64.66 کیلوبایت
نوع فایل pdf
تعداد صفحات 7

دانلود دیتاشیت NLU1GT86MUTCG

دانلود دیتاشیت

سایر مستندات

NLU1GT86 5 pages

NLU1GT86MUTCG 5 pages

مشخصات فنی

  • RoHS: true
  • Series: -
  • Category: Logic ICs/Gates
  • Datasheet: onsemi NLU1GT86MUTCG
  • Sink Current: 8mA
  • Source Current: 8mA
  • Supply Voltage: 1.65V~5.5V
  • Logic Gate Type: XORGate
  • Number of Channels: 1
  • Low Level Range (VIL): 0.53V~0.8V
  • Operating Temperature: -55°C~+125°C
  • High Level Range (VIH): 1.4V~2V
  • Propagation Delay Time: 8.8ns@5V,50pF
  • Quiescent Current (Max): 1uA
  • Package: DFN-6(1x1.2)
  • Manufacturer: onsemi
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Logic Type: XOR (Exclusive OR)
  • Number of Circuits: 1
  • Number of Inputs: 2
  • Features: -
  • Voltage - Supply: 1.65V ~ 5.5V
  • Current - Quiescent (Max): 1µA
  • Current - Output High, Low: 8mA, 8mA
  • Logic Level - Low: 0.53V ~ 0.8V
  • Logic Level - High: 1.4V ~ 2V
  • Max Propagation Delay @ V, Max CL: 8.8ns @ 5V, 50pF
  • Mounting Type: Surface Mount
  • Supplier Device Package: 6-UDFN (1.2x1)
  • Package / Case: 6-UFDFN
  • Base Part Number: NLU1GT86
  • detail: XOR (Exclusive OR) IC 1 Channel 6-UDFN (1.2x1)
