دیتاشیت CM1223-02SO

CM1223

مشخصات دیتاشیت

نام دیتاشیت CM1223
حجم فایل 337.332 کیلوبایت
نوع فایل pdf
تعداد صفحات 13

دانلود دیتاشیت CM1223

CM1223 Datasheet

مشخصات

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/TVS
  • Datasheet: onsemi CM1223-02SO
  • Breakdown Voltage: 6V
  • Unidirectional Channels: 2
  • Maximum Clamping Voltage: 8.8V
  • Reverse Stand-Off Voltage (Vrwm): 3.3V
  • Peak Pulse Current (Ipp)@10/1000us: 1A@8/20us
  • Package: SOT-23-5
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: Steering (Rail to Rail)
  • Voltage - Reverse Standoff (Typ): 3.3V
  • Voltage - Breakdown (Min): 6V
  • Voltage - Clamping (Max) @ Ipp: 8.8V (Typ)
  • Current - Peak Pulse (10/1000µs): 1A (8/20µs)
  • Power - Peak Pulse: -
  • Power Line Protection: Yes
  • Applications: General Purpose
  • Capacitance @ Frequency: -
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: SC-74A, SOT-753
  • Supplier Device Package: SOT-23-5
  • Base Part Number: CM1223
  • detail: 8.8V (Typ) Clamp 1A (8/20µs) Ipp Tvs Diode Surface Mount SOT-23-5
