دیتاشیت MC33269DR2G
مشخصات دیتاشیت
| نام دیتاشیت | MC33269DR2G |
|---|---|
| حجم فایل | 88.351 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 14 |
MC33269DR2G |
دانلود دیتاشیت |
|---|
سایر مستندات
MC33269, NCV33269 12 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: onsemi MC33269DR2G
- Output Type: Adjustable
- Output Current: 800mA
- Output Voltage: 1.25V~18.65V
- Dropout Voltage: 1.35V@(800mA)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 20V
- Operating Temperature: -40°C~+125°C
- Power Supply Rejection Ratio (PSRR): 55dB@(120Hz)
- Package: SOP-8
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Configuration: Positive
- Number of Regulators: 1
- Voltage - Input (Max): 20V
- Voltage - Output (Min/Fixed): 1.25V
- Voltage - Output (Max): 18.65V
- Voltage Dropout (Max): 1.35V @ 800mA
- Current - Output: 800mA
- PSRR: 55dB (120Hz)
- Control Features: -
- Protection Features: Over Temperature, Short Circuit
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 8-SOIC
- Base Part Number: MC33269
- detail: Linear Voltage Regulator IC 1 Output 800mA 8-SOIC
