NCS2250, NCV2250, NCS2252, NCV2252 دیتاشیت

NCS2250, NCV2250, NCS2252, NCV2252

مشخصات دیتاشیت

نام دیتاشیت NCS2250, NCV2250, NCS2252, NCV2252
حجم فایل 255.605 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

دانلود دیتاشیت NCS2250, NCV2250, NCS2252, NCV2252

دانلود دیتاشیت

سایر مستندات

NCS2250SQ2T2G 12 pages

مشخصات فنی

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Comparators
  • Datasheet: onsemi NCS2250SN2T1G
  • Output Type: Push Pull;轨到轨
  • Supply Voltage: 1.8V~5.5V
  • Operating Temperature: -40°C~+125°C
  • Input Bias Current (Ib): 20pA
  • Input Offset Voltage (Vos): 6mV
  • Input Hysteresis Voltage (Vhys): -
  • Common Mode Rejection Ratio (CMRR): 81dB
  • Package: SOT-23-5
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: General Purpose
  • Number of Elements: 1
  • Voltage - Supply, Single/Dual (±): 1.8V ~ 5.5V
  • Voltage - Input Offset (Max): 6mV @ 5V
  • Current - Input Bias (Max): 20pA @ 5V
  • Current - Output (Typ): 48mA
  • Current - Quiescent (Max): 200µA
  • CMRR, PSRR (Typ): 81dB CMRR, 88dB PSRR
  • Propagation Delay (Max): 64ns
  • Hysteresis: -
  • Package / Case: SOT-23-5 Thin, TSOT-23-5
  • Mounting Type: Surface Mount
  • Supplier Device Package: 5-TSOP
  • Base Part Number: NCS2250
  • detail: Comparator General Purpose Push-Pull, Rail-to-Rail 5-TSOP
