دیتاشیت TCA0372BDWR2G
مشخصات دیتاشیت
| نام دیتاشیت | TCA0372(B), NCV0372B |
|---|---|
| حجم فایل | 334.09 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 7 |
دانلود دیتاشیت TCA0372(B), NCV0372B |
TCA0372(B), NCV0372B Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Operational Amplifier/Comparator/Operational Amplifier
- Datasheet: onsemi TCA0372BDWR2G
- -3db Bandwidth: -
- Output Current: 1A
- Operating Temperature: -40°C~+125°C
- Current - Input Bias(Ib): 100nA
- Gain Bandwidth Product(GBP): 1.4MHz
- Package: SOP-16-300mil
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Amplifier Type: General Purpose
- Number of Circuits: 2
- Output Type: -
- Slew Rate: 1.4V/µs
- Gain Bandwidth Product: 1.4MHz
- Current - Input Bias: 100nA
- Voltage - Input Offset: 1mV
- Current - Supply: 8mA
- Current - Output / Channel: 1A
- Voltage - Supply, Single/Dual (±): 5V ~ 40V, ±2.5V ~ 20V
- Mounting Type: Surface Mount
- Package / Case: 16-SOIC (0.295", 7.50mm Width)
- Supplier Device Package: 16-SOIC
- Base Part Number: TCA0372
- detail: General Purpose Amplifier 2 Circuit 16-SOIC
