NLHV3157NDFT2G دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت NLHV3157NDFT2G	دانلود دیتاشیت

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: onsemi NLHV3157NDFT2G
Turn-on time: 220ns
Switch Circuit: SPDT(SPDT)
Number of Channels: 1
On-State Resistance (Max): 4.5Ω
Package: SC-88
Manufacturer: onsemi
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Multiplexer/Demultiplexer Circuit: 2:1
Number of Circuits: 1
Channel-to-Channel Matching (ΔRon): 200mOhm
Voltage - Supply, Single (V+): -
Voltage - Supply, Dual (V±): -
Switch Time (Ton, Toff) (Max): 220ns, 225ns
-3db Bandwidth: 220MHz
Charge Injection: 170pC
Channel Capacitance (CS(off), CD(off)): 6pF
Current - Leakage (IS(off)) (Max): 20µA
Crosstalk: -42dB @ 10MHz
Operating Temperature: -55°C ~ 125°C (TA)
Mounting Type: Surface Mount
Package / Case: 6-TSSOP, SC-88, SOT-363
Supplier Device Package: SC-88/SC70-6/SOT-363
Base Part Number: NLHV315
detail: 1 Circuit IC Switch 2:1 4.5Ohm SC-88/SC70-6/SOT-363
