دیتاشیت LV8417CS-TE-L-H

LV8417CS

مشخصات دیتاشیت

نام دیتاشیت LV8417CS
حجم فایل 166.49 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

دانلود دیتاشیت LV8417CS

LV8417CS Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Motor Type - Stepper: -
  • Motor Type - AC, DC: Brushed DC
  • Function: Driver - Fully Integrated, Control and Power Stage
  • Output Configuration: Half Bridge (2)
  • Interface: Parallel
  • Technology: BiCDMOS
  • Step Resolution: -
  • Applications: General Purpose
  • Current - Output: 1A
  • Voltage - Supply: 2.7V ~ 5.5V
  • Voltage - Load: 2V ~ 10.5V
  • Operating Temperature: -20°C ~ 85°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 9-UFBGA, WLBGA
  • Supplier Device Package: 9-WLP (1.47x1.47)
  • Base Part Number: LV841
  • detail: Motor Driver BiCDMOS Parallel 9-WLP (1.47x1.47)
