HCPL2530SD دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
HCPL2530SD
|
|
حجم فایل
|
72.113
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
15
|
مشخصات فنی
-
RoHS:
true
-
Category:
Optocoupler/LED/Digital Tube/Photoelectric Device/Optocouplers - Logic Output
-
Data Rate:
1Mbit/s
-
Datasheet:
onsemi HCPL2530SD
-
Input Type:
DC
-
Supply Voltage:
-
-
Number of Channels:
2
-
Operating Temperature:
-55°C~+100°C
-
Isolation Voltage(rms):
2500V
-
Propagation Delay tpLH/tpHL:
1.5us
-
Common Mode Transient Immunity (CMTI):
10kV/us
-
Package:
SOP-8-2.54mm
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Voltage - Isolation:
2500Vrms
-
Current Transfer Ratio (Min):
7% @ 16mA
-
Current Transfer Ratio (Max):
50% @ 16mA
-
Turn On / Turn Off Time (Typ):
450ns, 500ns
-
Rise / Fall Time (Typ):
-
-
Output Type:
Transistor
-
Voltage - Output (Max):
20V
-
Current - Output / Channel:
8mA
-
Voltage - Forward (Vf) (Typ):
1.45V
-
Current - DC Forward (If) (Max):
25mA
-
Vce Saturation (Max):
-
-
Mounting Type:
Surface Mount
-
Package / Case:
8-SMD, Gull Wing
-
Supplier Device Package:
8-SMD
-
Base Part Number:
HCPL25
-
detail:
Optoisolator Transistor Output 2500Vrms 2 Channel 8-SMD
