FDMC2514SDC دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت FDMC2514SDC	دانلود دیتاشیت

RoHS: true
Type: -
Category: Triode/MOS Tube/Transistor/MOSFETs
Datasheet: onsemi FDMC2514SDC
Power Dissipation (Pd): -
Total Gate Charge (Qg@Vgs): -
Drain Source Voltage (Vdss): -
Input Capacitance (Ciss@Vds): -
Continuous Drain Current (Id): -
Gate Threshold Voltage (Vgs(th)@Id): -
Reverse Transfer Capacitance (Crss@Vds): -
Drain Source On Resistance (RDS(on)@Vgs,Id): -
Package: DualCool-33
Manufacturer: onsemi
Series: Dual Cool™, PowerTrench®, SyncFET™
Packaging: Cut Tape (CT)
Part Status: Last Time Buy
FET Type: N-Channel
Technology: MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss): 25V
Current - Continuous Drain (Id) @ 25°C: 24A (Ta), 40A (Tc)
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Rds On (Max) @ Id, Vgs: 3.5mOhm @ 22.5A, 10V
Vgs(th) (Max) @ Id: 3V @ 1mA
Gate Charge (Qg) (Max) @ Vgs: 44nC @ 10V
Vgs (Max): ±20V
Input Capacitance (Ciss) (Max) @ Vds: 2705pF @ 13V
FET Feature: -
Power Dissipation (Max): 3W (Ta), 60W (Tc)
Operating Temperature: -55°C ~ 150°C (TJ)
Mounting Type: Surface Mount
Supplier Device Package: Dual Cool ™ 33
Package / Case: 8-PowerTDFN
Base Part Number: FDMC25
detail: N-Channel 25V 24A (Ta), 40A (Tc) 3W (Ta), 60W (Tc) Surface Mount Dual Cool ™ 33
