NCV8518BPDR2G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NCV8518BPDR2G
|
|
حجم فایل
|
176.54
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
13
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
onsemi NCV8518BPDR2G
-
Output Type:
Fixed
-
Output Current:
250mA
-
Output Voltage:
5V~5V
-
Dropout Voltage:
750mV@(150mA)
-
Output Polarity:
Positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
45V
-
Operating Temperature:
-40°C~+150°C
-
Quiescent Current (Ground Current):
150uA
-
Power Supply Rejection Ratio (PSRR):
-
-
Package:
SOIC-8-EP
-
Manufacturer:
onsemi
-
Series:
Automotive, AEC-Q100
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Number of Regulators:
1
-
Voltage - Input (Max):
45V
-
Voltage - Output (Min/Fixed):
5V
-
Voltage - Output (Max):
-
-
Voltage Dropout (Max):
0.75V @ 150mA
-
Current - Output:
250mA
-
Current - Quiescent (Iq):
150µA
-
PSRR:
-
-
Control Features:
Enable, Reset, Wake-Up, Watchdog
-
Protection Features:
Over Temperature, Short Circuit
-
Mounting Type:
Surface Mount
-
Package / Case:
8-SOIC (0.154", 3.90mm Width) Exposed Pad
-
Supplier Device Package:
8-SOIC-EP
-
Base Part Number:
NCV8518
-
detail:
Linear Voltage Regulator IC 1 Output 250mA 8-SOIC-EP
