MM74HCT273MTCX دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
MM74HCT273MTCX
|
|
حجم فایل
|
66.226
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
8
|
مشخصات فنی
-
RoHS:
true
-
Type:
D-Type
-
Series:
74HCT
-
Category:
Logic ICs/Flip Flops
-
Function:
Reset
-
Datasheet:
onsemi MM74HCT273MTCX
-
Output Type:
Non-Inverted
-
Sink Current:
4.8mA
-
Trigger Type:
上升沿
-
Source Current:
4.8mA
-
Supply Voltage:
4.5V~5.5V
-
Clock Frequency:
68MHz
-
Input Capacitance:
6pF
-
Number of Elements:
1
-
Operating Temperature:
-40°C~+85°C
-
Quiescent Current (Iq):
8uA
-
Maximum Propagation Delay:
37ns@5V,50pF
-
Number of Bits per Element:
8
-
Package:
TSSOP-20
-
Manufacturer:
onsemi
-
Packaging:
Tube
-
Part Status:
Active
-
Max Propagation Delay @ V, Max CL:
37ns @ 5V, 50pF
-
Current - Output High, Low:
4.8mA, 4.8mA
-
Voltage - Supply:
4.5V ~ 5.5V
-
Current - Quiescent (Iq):
8µA
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
20-TSSOP
-
Package / Case:
20-TSSOP (0.173", 4.40mm Width)
-
Base Part Number:
MM74H
-
detail:
Flip Flop 1 Element D-Type 8 Bit Positive Edge 20-TSSOP (0.173", 4.40mm Width)
