H11D1SR2M دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | H11D1SR2M |
|---|---|
| حجم فایل | 60.755 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 10 |
دانلود دیتاشیت H11D1SR2M |
دانلود دیتاشیت |
|---|
سایر مستندات
H11D1M-3M, 4N38M, MOC8204M 13 pages
مشخصات فنی
- RoHS: true
- Category: Optocoupler/LED/Digital Tube/Photoelectric Device/Optocouplers - Phototransistor Output
- Datasheet: onsemi H11D1SR2M
- Output Current: 100mA
- Forward Voltage: 1.15V
- Number of Outputs: 1
- Operating Temperature: -40°C~+100°C
- Isolation Voltage(rms): 4170V
- Package: SMD-6P
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Number of Channels: 1
- Voltage - Isolation: 4170Vrms
- Current Transfer Ratio (Min): 20% @ 10mA
- Current Transfer Ratio (Max): -
- Turn On / Turn Off Time (Typ): 5µs, 5µs
- Rise / Fall Time (Typ): -
- Input Type: DC
- Output Type: Transistor with Base
- Voltage - Output (Max): 300V
- Current - Output / Channel: 100mA
- Voltage - Forward (Vf) (Typ): 1.15V
- Current - DC Forward (If) (Max): 80mA
- Vce Saturation (Max): 400mV
- Mounting Type: Surface Mount
- Package / Case: 6-SMD, Gull Wing
- Supplier Device Package: 6-SMD
- Base Part Number: H11D
- detail: Optoisolator Transistor with Base Output 4170Vrms 1 Channel 6-SMD
