- دیتاشیت NCP692MN33T2G
NCP692MN33T2G دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | NCP692MN33T2G |
|---|---|
| حجم فایل | 90.969 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 15 |
دانلود دیتاشیت NCP692MN33T2G |
دانلود دیتاشیت |
|---|
سایر مستندات
NCP690-92, NCV8690 15 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: onsemi NCP692MN33T2G
- Output Type: Fixed
- Output Current: 1A
- Output Voltage: 3.3V
- Dropout Voltage: 250mV@(1A)
- Output Polarity: Positive
- Number of Outputs: 1
- Maximum Input Voltage: 6V
- Operating Temperature: -40°C~+85°C
- Quiescent Current (Ground Current): 200uA
- Power Supply Rejection Ratio (PSRR): -
- Package: DFN-6(3x3)
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Configuration: Positive
- Number of Regulators: 1
- Voltage - Input (Max): 6V
- Voltage - Output (Min/Fixed): 3.3V
- Voltage - Output (Max): -
- Voltage Dropout (Max): 0.25V @ 1A
- Current - Output: 1A
- Current - Quiescent (Iq): 200µA
- Current - Supply (Max): 240µA
- PSRR: -
- Control Features: Enable
- Protection Features: Over Temperature, Short Circuit
- Mounting Type: Surface Mount
- Package / Case: 6-VDFN Exposed Pad
- Supplier Device Package: 6-DFN (3x3)
- Base Part Number: NCP692
- detail: Linear Voltage Regulator IC 1 Output 1A 6-DFN (3x3)
