دیتاشیت FFSB0865B-F085
مشخصات دیتاشیت
| نام دیتاشیت |
FFSB0865B-F085
|
| حجم فایل |
269.966
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
6
|
مشخصات
-
RoHS:
true
-
Category:
Diodes/Schottky Barrier Diodes (SBD)
-
Datasheet:
onsemi FFSB0865B-F085
-
Diode Configuration:
Single
-
Reverse Voltage (Vr):
650V
-
Forward Voltage (Vf@If):
1.39V@8A
-
Reverse Leakage Current (Ir):
500nA@650V
-
Average Rectified Current (Io):
10.1A
-
Package:
D2PAK
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Diode Type:
Silicon Carbide Schottky
-
Voltage - DC Reverse (Vr) (Max):
650V
-
Current - Average Rectified (Io):
10.1A (DC)
-
Voltage - Forward (Vf) (Max) @ If:
1.7V @ 8A
-
Speed:
No Recovery Time > 500mA (Io)
-
Reverse Recovery Time (trr):
0ns
-
Current - Reverse Leakage @ Vr:
40µA @ 650V
-
Capacitance @ Vr, F:
336pF @ 1V, 100kHz
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
-
Supplier Device Package:
D²PAK-2 (TO-263-2)
-
Operating Temperature - Junction:
-55°C ~ 175°C
-
Base Part Number:
FFSB08
-
detail:
Diode Silicon Carbide Schottky 650V 10.1A (DC) Surface Mount D²PAK-2 (TO-263-2)
