دیتاشیت MC33166D2TR4G
مشخصات دیتاشیت
| نام دیتاشیت |
MC34166, 33166
|
| حجم فایل |
303.152
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
18
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
boost converterType;Step-down type
-
Topology:
Step-down;Boost
-
Datasheet:
onsemi MC33166D2TR4G
-
Output Type:
Adjustable
-
Input Voltage:
7.5V~40V
-
Output Voltage:
5.05V~40V
-
Number of Outputs:
1
-
Switching Frequency:
72kHz
-
Output Current (Max):
3.3A
-
Operating Temperature:
-40°C~+85°C@(TA)
-
Synchronous Rectification:
NO
-
Package:
D2PAK
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Obsolete
-
Output Configuration:
Positive or Negative
-
Voltage - Input (Min):
7.5V
-
Voltage - Input (Max):
40V
-
Voltage - Output (Min/Fixed):
5.05V
-
Voltage - Output (Max):
40V (Switch)
-
Current - Output:
3.3A (Switch)
-
Frequency - Switching:
72kHz
-
Synchronous Rectifier:
No
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-263-6, D²Pak (5 Leads + Tab), TO-263BA
-
Supplier Device Package:
D2PAK-5
-
Base Part Number:
MC33166
-
detail:
Buck, Boost Switching Regulator IC Positive or Negative Adjustable 5.05V 1 Output 3.3A (Switch) TO-263-6, D²Pak (5 Leads + Tab), TO-263BA
