NCP/NCV565 دیتاشیت

NCP/NCV565

مشخصات دیتاشیت

نام دیتاشیت NCP/NCV565
حجم فایل 196.206 کیلوبایت
نوع فایل pdf
تعداد صفحات 15

دانلود دیتاشیت NCP/NCV565

دانلود دیتاشیت

سایر مستندات

onsemi NCV565D2T12R4G 17 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: onsemi NCP565D2T33R4G
  • Output Type: Fixed
  • Output Current: 1.5A
  • Output Voltage: 3.3V
  • Dropout Voltage: -
  • Output Polarity: Positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 9V
  • Power Supply Rejection Ratio (PSRR): 85dB@(120Hz),75dB@(1kHz)
  • Package: TO-263
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Output Configuration: Positive
  • Number of Regulators: 1
  • Voltage - Input (Max): 9V
  • Voltage - Output (Min/Fixed): 3.3V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): -
  • Current - Output: 1.5A
  • Current - Quiescent (Iq): 3mA
  • PSRR: 85dB ~ 75db (120Hz ~ 1kHz)
  • Control Features: -
  • Protection Features: Over Current, Over Temperature
  • Operating Temperature: -40°C ~ 125°C
  • Mounting Type: Surface Mount
  • Package / Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
  • Supplier Device Package: D2PAK
  • Base Part Number: NCP565
  • detail: Linear Voltage Regulator IC 1 Output 1.5A D2PAK
