FS8G دیتاشیت

FS8G

مشخصات دیتاشیت

نام دیتاشیت FS8G
حجم فایل 57.132 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

مشاهده دیتاشیت FS8G

دانلود دیتاشیت

سایر مستندات

FS8G - FS8M 6 pages

مشخصات فنی

  • RoHS: true
  • Category: Diodes/Diodes - General Purpose
  • Datasheet: onsemi FS8G
  • Diode Configuration: Single
  • Reverse Voltage (Vr): 400V
  • Forward Voltage (Vf@If): 951mV@8A
  • Reverse Leakage Current: 370nA@400V
  • Average Rectified Current (Io): 8A
  • Package: TO-277
  • Manufacturer: onsemi
  • Series: Automotive, AEC-Q101
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 400V
  • Current - Average Rectified (Io): 8A
  • Voltage - Forward (Vf) (Max) @ If: 1.1V @ 8A
  • Speed: Standard Recovery >500ns, > 200mA (Io)
  • Reverse Recovery Time (trr): 3.37µs
  • Current - Reverse Leakage @ Vr: 5µA @ 400V
  • Capacitance @ Vr, F: 118pF @ 0V, 1MHz
  • Mounting Type: Surface Mount
  • Package / Case: TO-277, 3-PowerDFN
  • Supplier Device Package: TO-277-3
  • Operating Temperature - Junction: -55°C ~ 150°C
  • Base Part Number: FS8G
  • detail: Diode Standard 400V 8A Surface Mount TO-277-3
