NCP3135MNTXG دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NCP3135MNTXG
|
|
حجم فایل
|
74.668
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
13
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
Step-down type
-
Topology:
Step-down
-
Datasheet:
onsemi NCP3135MNTXG
-
Output Type:
Adjustable
-
Input Voltage:
2.9V~5.5V
-
Output Voltage:
0.6V~4.62V
-
Number of Outputs:
1
-
Switching Frequency:
-
-
Output Current (Max):
5A
-
Operating Temperature:
-40°C~+85°C@(TA)
-
Synchronous Rectification:
Yes
-
Package:
QFN-16-EP(3x3)
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Voltage - Input (Min):
2.9V
-
Voltage - Input (Max):
5.5V
-
Voltage - Output (Min/Fixed):
0.6V
-
Voltage - Output (Max):
4.62V
-
Current - Output:
5A
-
Frequency - Switching:
-
-
Synchronous Rectifier:
Yes
-
Mounting Type:
Surface Mount
-
Package / Case:
16-VFQFN Exposed Pad
-
Supplier Device Package:
16-QFN (3x3)
-
Base Part Number:
NCP3135
-
detail:
Buck Switching Regulator IC Positive Adjustable 0.6V 1 Output 5A 16-VFQFN Exposed Pad
