NUP4201DR2G دیتاشیت

NUP4201DR2G

مشخصات دیتاشیت

نام دیتاشیت NUP4201DR2G
حجم فایل 81.202 کیلوبایت
نوع فایل pdf
تعداد صفحات 10

مشاهده دیتاشیت NUP4201DR2G

دانلود دیتاشیت

سایر مستندات

NUP4201DR2 9 pages

مشخصات فنی

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/TVS
  • Datasheet: onsemi NUP4201DR2G
  • Breakdown Voltage: 6V
  • Unidirectional Channels: 4
  • Maximum Clamping Voltage: 25V
  • Reverse Stand-Off Voltage (Vrwm): 5V
  • Peak Pulse Current (Ipp)@10/1000μs: 25A@8/20us
  • Peak Pulse Power Dissipation (Ppp)@10/1000μs: 500W
  • Package: SOIC-8
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Obsolete
  • Type: Steering (Rail to Rail)
  • Voltage - Reverse Standoff (Typ): 5V
  • Voltage - Breakdown (Min): 6V
  • Voltage - Clamping (Max) @ Ipp: 25V
  • Current - Peak Pulse (10/1000µs): 25A (8/20µs)
  • Power - Peak Pulse: 500W
  • Power Line Protection: Yes
  • Applications: General Purpose
  • Capacitance @ Frequency: 5pF @ 1MHz
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 8-SOIC
  • Base Part Number: NUP4201
  • detail: 25V Clamp 25A (8/20µs) Ipp Tvs Diode Surface Mount 8-SOIC
