MC74VHC1G14, MC74VHC1GT14 دیتاشیت

MC74VHC1G14, MC74VHC1GT14

مشخصات دیتاشیت

نام دیتاشیت MC74VHC1G14, MC74VHC1GT14
حجم فایل 190.172 کیلوبایت
نوع فایل pdf
تعداد صفحات 15

دانلود دیتاشیت MC74VHC1G14, MC74VHC1GT14

دانلود دیتاشیت

سایر مستندات

MC74VHC1G14DFT1G 15 pages

مشخصات فنی

  • RoHS: true
  • Category: Logic ICs/Inverters
  • Datasheet: onsemi MC74VHC1G14DTT1G
  • Package: TSOP-5-1.5mm
  • Manufacturer: onsemi
  • Series: 74VHC
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Logic Type: Inverter
  • Number of Circuits: 1
  • Number of Inputs: 1
  • Features: Schmitt Trigger
  • Voltage - Supply: 2V ~ 5.5V
  • Current - Quiescent (Max): 1µA
  • Current - Output High, Low: 8mA, 8mA
  • Logic Level - Low: 0.9V ~ 1.65V
  • Logic Level - High: 2.2V ~ 3.85V
  • Max Propagation Delay @ V, Max CL: 10.6ns @ 5V, 50pF
  • Operating Temperature: -55°C ~ 125°C
  • Mounting Type: Surface Mount
  • Supplier Device Package: 5-TSOP
  • Package / Case: SOT-23-5 Thin, TSOT-23-5
  • Base Part Number: MC74VHC1G14
  • detail: Inverter IC 1 Channel Schmitt Trigger 5-TSOP
