دیتاشیت NC7SB3157, FSA3157
مشخصات دیتاشیت
| نام دیتاشیت | NC7SB3157, FSA3157 |
|---|---|
| حجم فایل | 1044.381 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 11 |
NC7SB3157, FSA3157 |
دانلود دیتاشیت |
|---|
سایر مستندات
FSA3157L6X 10 pages
مشخصات فنی
- Manufacturer: ON Semiconductor
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Switch Circuit: SPDT
- Multiplexer/Demultiplexer Circuit: 2:1
- Number of Circuits: 1
- On-State Resistance (Max): 15Ohm
- Channel-to-Channel Matching (ΔRon): 150mOhm
- Voltage - Supply, Single (V+): 1.65V ~ 5.5V
- Voltage - Supply, Dual (V±): -
- Switch Time (Ton, Toff) (Max): 5.7ns, 3.8ns
- -3db Bandwidth: 250MHz
- Charge Injection: 7pC
- Channel Capacitance (CS(off), CD(off)): 6.5pF
- Current - Leakage (IS(off)) (Max): 100nA
- Crosstalk: -54dB @ 10MHz
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 6-TSSOP, SC-88, SOT-363
- Supplier Device Package: SC-88 (SC-70-6)
- Base Part Number: FSA31
- detail: 1 Circuit IC Switch 2:1 15Ohm SC-88 (SC-70-6)
