- دیتاشیت UC3844B, 3845B, 2844B, 2845B
دیتاشیت UC3844B, 3845B, 2844B, 2845B
مشخصات دیتاشیت
| نام دیتاشیت | UC3844B, 3845B, 2844B, 2845B |
|---|---|
| حجم فایل | 589.859 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 22 |
UC3844B, 3845B, 2844B, 2845B |
دانلود دیتاشیت |
|---|
سایر مستندات
UC3844BD1R2G 19 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/DC-DC Controllers
- Function: boost converterType;Buck-boost type
- Topology: Boost;Flyback
- Datasheet: onsemi UC2844BD1R2G
- Input Voltage: 10V~36V
- Duty Cycle (Max): 48%
- Number of Outputs: 1
- Switching Frequency: 500kHz
- Operating Temperature: -25°C~+85°C@(TA)
- Synchronous Rectification: NO
- Package: SOIC-8
- Manufacturer: onsemi
- Duty Cycle: 48%
- Supply Voltage: 10V~36V
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Type: Transistor Driver
- Output Configuration: Positive
- Output Phases: 1
- Voltage - Supply (Vcc/Vdd): 10V ~ 36V
- Frequency - Switching: Up to 500kHz
- Synchronous Rectifier: No
- Clock Sync: No
- Serial Interfaces: -
- Control Features: Frequency Control
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 8-SOIC
- Base Part Number: UC284
- detail: Boost, Flyback Regulator Positive Output Step-Up, Step-Up/Step-Down DC-DC Controller IC 8-SOIC
