NCS2220AMUT1G دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت NCS2220AMUT1G	دانلود دیتاشیت

RoHS: true
Category: Operational Amplifier/Comparator/Comparators
Datasheet: onsemi NCS2220AMUT1G
Output Type: 互补;轨到轨
Supply Voltage: 0.85V~6V
Number of Elements: -
Operating Temperature: -40°C~+105°C
Input Bias Current (Ib): 1pA
Input Offset Voltage (Vos): 5mV
Input Hysteresis Voltage (Vhys): 20mV
Common Mode Rejection Ratio (CMRR): 53dB
Package: DFN-8(1.6x1.6)
Manufacturer: onsemi
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Type: General Purpose
Voltage - Supply, Single/Dual (±): 0.85V ~ 6V
Voltage - Input Offset (Max): 5mV @ 6V
Current - Input Bias (Max): 1pA @ 6V
Current - Output (Typ): -
Current - Quiescent (Max): 17µA
CMRR, PSRR (Typ): 53dB CMRR, 45dB PSRR
Propagation Delay (Max): 500ns
Hysteresis: 20mV
Package / Case: 8-UFDFN Exposed Pad
Mounting Type: Surface Mount
Supplier Device Package: 8-UDFN (1.6x1.6)
Base Part Number: NCS2220
detail: Comparator General Purpose Complementary, Rail-to-Rail 8-UDFN (1.6x1.6)
