NCP1338DR2G دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت NCP1338DR2G	دانلود دیتاشیت

NCP1338 15 pages

RoHS: true
Category: Power Supply Chip/Power Modules
Datasheet: onsemi NCP1338DR2G
Package: SOP-7
Manufacturer: onsemi
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Output Isolation: Isolated
Internal Switch(s): No
Voltage - Breakdown: -
Topology: Flyback
Voltage - Start Up: 12V
Voltage - Supply (Vcc/Vdd): 10V ~ 20V
Duty Cycle: -
Frequency - Switching: 130kHz
Fault Protection: Current Limiting, Over Temperature, Over Voltage, Short Circuit
Control Features: -
Operating Temperature: -40°C ~ 150°C (TJ)
Package / Case: 8-SOIC (0.154", 3.90mm Width), 7 Leads
Supplier Device Package: 7-SOIC
Mounting Type: Surface Mount
Base Part Number: NCP1338
detail: Converter Offline Flyback Topology 130kHz 7-SOIC
