- دیتاشیت MC33152PG
MC33152PG دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MC33152PG |
|---|---|
| حجم فایل | 84.088 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 14 |
دانلود دیتاشیت MC33152PG |
دانلود دیتاشیت |
|---|
سایر مستندات
MC34152, MC33152, NCV33152 12 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/Gate Drive ICs
- Datasheet: onsemi MC33152PG
- Fall Time: 32ns
- Load Type: MOSFET
- Rise Time: 36ns
- Supply Voltage: 6.1V~18V
- Number of Drivers: 2
- Driven Configuration: Low Side
- Operating Temperature: -40°C~+150°C@(Tj)
- Peak Output Current(sink): 1.5A
- Peak Output Current(source): 1.5A
- Package: DIP-8
- Manufacturer: onsemi
- Series: -
- Packaging: Tube
- Part Status: Obsolete
- Channel Type: Independent
- Gate Type: N-Channel MOSFET
- Voltage - Supply: 6.1V ~ 18V
- Logic Voltage - VIL, VIH: 0.8V, 2.6V
- Current - Peak Output (Source, Sink): 1.5A, 1.5A
- Input Type: Non-Inverting
- Rise / Fall Time (Typ): 36ns, 32ns
- Mounting Type: Through Hole
- Package / Case: 8-DIP (0.300", 7.62mm)
- Supplier Device Package: 8-PDIP
- Base Part Number: MC33152
- detail: Low-Side Gate Driver IC Non-Inverting 8-PDIP
