FDMS8320LDC دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
FDMS8320LDC
|
|
حجم فایل
|
75.551
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
8
|
مشخصات فنی
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
onsemi FDMS8320LDC
-
Package:
DualCool-56-8
-
Manufacturer:
onsemi
-
Series:
Dual Cool™, PowerTrench®
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
FET Type:
N-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
40V
-
Current - Continuous Drain (Id) @ 25°C:
44A (Ta), 130A (Tc)
-
Drive Voltage (Max Rds On, Min Rds On):
4.5V, 10V
-
Rds On (Max) @ Id, Vgs:
1.1mOhm @ 44A, 10V
-
Vgs(th) (Max) @ Id:
3V @ 250µA
-
Gate Charge (Qg) (Max) @ Vgs:
170nC @ 10V
-
Vgs (Max):
±20V
-
Input Capacitance (Ciss) (Max) @ Vds:
11635pF @ 20V
-
FET Feature:
-
-
Power Dissipation (Max):
3.2W (Ta), 125W (Tc)
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
Dual Cool™56
-
Package / Case:
8-PowerTDFN
-
Base Part Number:
FDMS83
-
detail:
N-Channel 40V 44A (Ta), 130A (Tc) 3.2W (Ta), 125W (Tc) Surface Mount Dual Cool™56
