NVMTS0D4N04CTXG دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت NVMTS0D4N04CTXG	دانلود دیتاشیت

RoHS: true
Category: Triode/MOS Tube/Transistor/MOSFETs
Datasheet: onsemi NVMTS0D4N04CTXG
Package: DFNW-8(8.4x8.3)
Manufacturer: onsemi
Series: Automotive, AEC-Q101
Packaging: Cut Tape (CT)
Part Status: Active
FET Type: N-Channel
Technology: MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss): 40V
Current - Continuous Drain (Id) @ 25°C: 79.8A (Ta), 558A (Tc)
Drive Voltage (Max Rds On, Min Rds On): 10V
Rds On (Max) @ Id, Vgs: 0.45mOhm @ 50A, 10V
Vgs(th) (Max) @ Id: 4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs: 251nC @ 10V
Vgs (Max): ±20V
Input Capacitance (Ciss) (Max) @ Vds: 16500pF @ 20V
FET Feature: -
Power Dissipation (Max): 5W
Operating Temperature: -55°C ~ 175°C (TJ)
Mounting Type: Surface Mount
Supplier Device Package: 8-DFNW (8.3x8.4)
Package / Case: 8-PowerTDFN
Base Part Number: NVMTS0
detail: N-Channel 40V 79.8A (Ta), 558A (Tc) 5W Surface Mount 8-DFNW (8.3x8.4)
