NSR01F30NXT5G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NSR01F30NXT5G
|
|
حجم فایل
|
83.027
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
5
|
مشخصات فنی
-
RoHS:
true
-
Category:
Diodes/Schottky Barrier Diodes (SBD)
-
Datasheet:
onsemi NSR01F30NXT5G
-
Diode Configuration:
Single
-
Reverse Voltage (Vr):
30V
-
Forward Voltage (Vf@If):
500mV@100mA
-
Reverse Leakage Current (Ir):
50uA@30V
-
Average Rectified Current (Io):
100mA
-
Package:
DSN-2
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Diode Type:
Schottky
-
Voltage - DC Reverse (Vr) (Max):
30V
-
Current - Average Rectified (Io):
100mA (DC)
-
Voltage - Forward (Vf) (Max) @ If:
500mV @ 100mA
-
Speed:
Small Signal =< 200mA (Io), Any Speed
-
Current - Reverse Leakage @ Vr:
50µA @ 30V
-
Capacitance @ Vr, F:
7pF @ 5V, 1MHz
-
Mounting Type:
Surface Mount
-
Package / Case:
0201 (0603 Metric)
-
Supplier Device Package:
2-DSN (0.60x0.30)
-
Operating Temperature - Junction:
125°C (Max)
-
Base Part Number:
NSR01F
-
detail:
Diode Schottky 30V 100mA (DC) Surface Mount 2-DSN (0.60x0.30)
