NCV8675DS50R4G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NCV8675DS50R4G
|
|
حجم فایل
|
86.463
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
17
|
مشخصات فنی
-
RoHS:
true
-
Feature:
Thermal Protection;Overvoltage protection;Reverse connection protection
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
onsemi NCV8675DS50R4G
-
Output Current:
350mA
-
Output Voltage:
5V
-
Dropout Voltage:
0.6V@(350mA)
-
Output Polarity:
positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
45V
-
Operating Temperature:
-40°C~+150°C
-
Quiescent Current (Ground Current):
45uA
-
Power Supply Rejection Ratio (PSRR):
70dB@(100Hz)
-
Package:
D2PAK
-
Manufacturer:
onsemi
-
Series:
Automotive, AEC-Q100
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Output Type:
Fixed
-
Number of Regulators:
1
-
Voltage - Input (Max):
45V
-
Voltage - Output (Min/Fixed):
5V
-
Voltage - Output (Max):
-
-
Voltage Dropout (Max):
0.6V @ 350mA
-
Current - Output:
350mA
-
Current - Quiescent (Iq):
45µA
-
Current - Supply (Max):
60µA
-
PSRR:
70dB (100Hz)
-
Control Features:
Reset
-
Protection Features:
Over Temperature, Over Voltage, Reverse Polarity, Short Circuit
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-263-6, D²Pak (5 Leads + Tab), TO-263BA
-
Supplier Device Package:
D2PAK-5
-
Base Part Number:
NCV8675
-
detail:
Linear Voltage Regulator IC 1 Output 350mA D2PAK-5
