دیتاشیت 74AC32SCX

74AC32, 74ACT32

مشخصات دیتاشیت

نام دیتاشیت 74AC32, 74ACT32
حجم فایل 345.589 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

دانلود دیتاشیت 74AC32, 74ACT32

74AC32, 74ACT32 Datasheet

مشخصات

  • RoHS: true
  • Category: Logic ICs/Gates
  • Datasheet: onsemi 74AC32SCX
  • Package: SOIC-14-Narrow
  • Manufacturer: onsemi
  • Series: 74AC
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Logic Type: OR Gate
  • Number of Circuits: 4
  • Number of Inputs: 2
  • Features: -
  • Voltage - Supply: 2V ~ 6V
  • Current - Quiescent (Max): 2µA
  • Current - Output High, Low: 24mA, 24mA
  • Logic Level - Low: 0.9V ~ 1.65V
  • Logic Level - High: 2.1V ~ 3.85V
  • Max Propagation Delay @ V, Max CL: 7.5ns @ 5V, 50pF
  • Operating Temperature: -40°C ~ 85°C
  • Mounting Type: Surface Mount
  • Supplier Device Package: 14-SOIC
  • Package / Case: 14-SOIC (0.154", 3.90mm Width)
  • Base Part Number: 74AC32
  • detail: OR Gate IC 4 Channel 14-SOIC
