NRVTS5100ETFSWFTAG دیتاشیت

NRVTS5100ETFSWFTAG

مشخصات دیتاشیت

نام دیتاشیت NRVTS5100ETFSWFTAG
حجم فایل 79.798 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

مشاهده دیتاشیت NRVTS5100ETFSWFTAG

دانلود دیتاشیت

سایر مستندات

NRVTS5100ETFS 5 pages

مشخصات فنی

  • RoHS: true
  • Category: Diodes/Schottky Barrier Diodes (SBD)
  • Datasheet: onsemi NRVTS5100ETFSWFTAG
  • Diode Configuration: -
  • Reverse Voltage (Vr): 100V
  • Forward Voltage (Vf@If): 950mV@5A
  • Reverse Leakage Current (Ir): 1.5uA@100V
  • Average Rectified Current (Io): 5A
  • Package: DFN-8(3.3x3.3)
  • Manufacturer: onsemi
  • Series: Automotive, AEC-Q101
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Diode Type: Schottky
  • Voltage - DC Reverse (Vr) (Max): 100V
  • Current - Average Rectified (Io): 5A
  • Voltage - Forward (Vf) (Max) @ If: 1V @ 5A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 50µA @ 100V
  • Capacitance @ Vr, F: 26.5pF @ 100V, 1MHz
  • Mounting Type: Surface Mount
  • Package / Case: 8-PowerWDFN
  • Supplier Device Package: 8-WDFN (3.3x3.3)
  • Operating Temperature - Junction: -65°C ~ 175°C
  • Base Part Number: NRVTS51
  • detail: Diode Schottky 100V 5A Surface Mount 8-WDFN (3.3x3.3)
