NCP164CSN300T1G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NCP164CSN300T1G
|
|
حجم فایل
|
89.623
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
15
|
مشخصات فنی
-
RoHS:
true
-
Feature:
enable
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
onsemi NCP164CSN300T1G
-
Output Type:
Fixed
-
Output Current:
300mA
-
Output Voltage:
3V
-
Dropout Voltage:
177mV@(300mA)
-
Output Polarity:
Positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
5V
-
Quiescent Current (Ground Current):
40uA
-
Power Supply Rejection Ratio (PSRR):
83dB@(100Hz),61dB@(100kHz)
-
Package:
TSOP-5-1.5mm
-
Manufacturer:
onsemi
-
Series:
Automotive, AEC-Q100
-
Part Status:
Active
-
Output Configuration:
Positive
-
Number of Regulators:
1
-
Voltage - Input (Max):
5V
-
Voltage - Output (Min/Fixed):
3V
-
Voltage - Output (Max):
-
-
Voltage Dropout (Max):
0.177V @ 300mA
-
Current - Output:
300mA
-
Current - Quiescent (Iq):
40µA
-
PSRR:
83dB ~ 61dB (100Hz ~ 100kHz)
-
Control Features:
Enable
-
Protection Features:
Over Current, Over Temperature
-
Operating Temperature:
-40°C ~ 150°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
SOT-23-5 Thin, TSOT-23-5
-
Supplier Device Package:
5-TSOP
-
detail:
Linear Voltage Regulator IC 1 Output 300mA 5-TSOP
