NCV8775CDT50RKG دیتاشیت

NCV8775CDT50RKG

مشخصات دیتاشیت

نام دیتاشیت NCV8775CDT50RKG
حجم فایل 74.311 کیلوبایت
نوع فایل pdf
تعداد صفحات 15

مشاهده دیتاشیت NCV8775CDT50RKG

دانلود دیتاشیت

سایر مستندات

NCV8775C 15 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: onsemi NCV8775CDT50RKG
  • Output Type: Fixed
  • Output Current: 350mA
  • Output Voltage: 5V
  • Dropout Voltage: 600mV@(350mA)
  • Output Polarity: Positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 40V
  • Operating Temperature: -40°C~+150°C@(Tj)
  • Quiescent Current (Ground Current): 28uA
  • Power Supply Rejection Ratio (PSRR): 80dB@(100Hz)
  • Package: DPAK-5
  • Manufacturer: onsemi
  • Series: Automotive, AEC-Q100
  • Part Status: Active
  • Output Configuration: Positive
  • Number of Regulators: 1
  • Voltage - Input (Max): 40V
  • Voltage - Output (Min/Fixed): 5V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.6V @ 350mA
  • Current - Output: 350mA
  • Current - Quiescent (Iq): 28µA
  • PSRR: 80dB (100Hz)
  • Control Features: -
  • Protection Features: Over Current, Over Temperature
  • Mounting Type: Surface Mount
  • Package / Case: TO-252-5, DPak (4 Leads + Tab), TO-252AD
  • Supplier Device Package: DPAK-5
  • detail: Linear Voltage Regulator IC 1 Output 350mA DPAK-5
