دیتاشیت NCV57001FDWR2G
مشخصات دیتاشیت
| نام دیتاشیت |
NCV57001
|
| حجم فایل |
152.535
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
11
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Gate Drive ICs
-
Datasheet:
onsemi NCV57001FDWR2G
-
Fall Time:
19ns
-
Rise Time:
14ns
-
Number of Drivers:
1
-
Operating Temperature:
-40°C~+125°C@(Ta)
-
Peak Output Current(sink):
7.1A
-
Peak Output Current(source):
7.8A
-
Package:
SOP-16-300mil
-
Manufacturer:
onsemi
-
Series:
Automotive, AEC-Q100
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Technology:
Capacitive Coupling
-
Number of Channels:
1
-
Voltage - Isolation:
1200Vrms
-
Common Mode Transient Immunity (Min):
100kV/µs
-
Propagation Delay tpLH / tpHL (Max):
90ns, 90ns
-
Pulse Width Distortion (Max):
15ns
-
Rise / Fall Time (Typ):
14ns, 19ns
-
Current - Output High, Low:
7.8A, 7.1A
-
Current - Peak Output:
6A
-
Voltage - Forward (Vf) (Typ):
-
-
Voltage - Output Supply:
0V ~ 24V
-
Mounting Type:
Surface Mount
-
Package / Case:
16-SOIC (0.295", 7.50mm Width) Exposed Pad
-
Supplier Device Package:
16-SOIC
-
Approval Agency:
UL, VDE
-
detail:
6A Gate Driver Capacitive Coupling 1200Vrms 1 Channel 16-SOIC
