NL17SZ38DBVT1G دیتاشیت

NL17SZ38DBVT1G

مشخصات دیتاشیت

نام دیتاشیت NL17SZ38DBVT1G
حجم فایل 54.764 کیلوبایت
نوع فایل pdf
تعداد صفحات 10

مشاهده دیتاشیت NL17SZ38DBVT1G

دانلود دیتاشیت

سایر مستندات

NL17SZ38 10 pages

مشخصات فنی

  • RoHS: true
  • Series: 7SZ
  • Category: Logic ICs/Gates
  • Datasheet: onsemi NL17SZ38DBVT1G
  • Sink Current: 32mA
  • Source Current: -
  • Supply Voltage: 1.65V~5.5V
  • Logic Gate Type: NAND Gates
  • Number of Channels: 1
  • Operating Temperature: -55°C~+125°C
  • Propagation Delay Time: 4.3ns@5V,50pF
  • Quiescent Current (Max): 1uA
  • Package: SC-74A-5
  • Manufacturer: onsemi
  • Part Status: Active
  • Logic Type: NAND Gate
  • Number of Circuits: 1
  • Number of Inputs: 2
  • Features: Open Drain
  • Voltage - Supply: 1.65V ~ 5.5V
  • Current - Quiescent (Max): 1µA
  • Current - Output High, Low: -, 32mA
  • Logic Level - Low: -
  • Logic Level - High: -
  • Max Propagation Delay @ V, Max CL: 4.3ns @ 5V, 50pF
  • Mounting Type: Surface Mount
  • Supplier Device Package: SC-74
  • Package / Case: SC-74, SOT-457
  • detail: NAND Gate IC 1 Channel Open Drain SC-74
