ESDM3032MXT5G دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت ESDM3032MXT5G	دانلود دیتاشیت

RoHS: true
Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
Datasheet: onsemi ESDM3032MXT5G
Clamping Voltage@Ipp: 9.7V
Operating Temperature: -55°C~+150°C@(Tj)
Breakdown Voltage (VBR): 4.1V
Peak Pulse Power(Ppp)@8/20us: -
Junction Capacitance(Cj)@1MHz: 8.5pF@1MHz
Reverse Stand-Off Voltage (Vrwm): 3.3V
Package: X3-DFN-2
Manufacturer: onsemi
Series: -
Packaging: Tape & Reel (TR)
Part Status: Active
Type: Zener
Bidirectional Channels: 1
Voltage - Reverse Standoff (Typ): 3.3V (Max)
Voltage - Breakdown (Min): 4.1V
Voltage - Clamping (Max) @ Ipp: 9.7V
Current - Peak Pulse (10/1000µs): 8.5A (8/20µs)
Power - Peak Pulse: -
Power Line Protection: No
Applications: General Purpose
Capacitance @ Frequency: 8.5pF @ 1MHz
Mounting Type: Surface Mount
Package / Case: 0201 (0603 Metric)
Supplier Device Package: 2-X3DFN (0.62x0.32)
Base Part Number: ESDM3
detail: 9.7V Clamp 8.5A (8/20µs) Ipp Tvs Diode Surface Mount 2-X3DFN (0.62x0.32)
