ESDM1051MX4T5G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
ESDM1051MX4T5G
|
|
حجم فایل
|
67.593
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
7
|
مشخصات فنی
-
RoHS:
true
-
Category:
TVS/Fuse/Board Level Protection/ESD Protection Devices
-
Datasheet:
onsemi ESDM1051MX4T5G
-
Number of Lines:
1
-
Clamping Voltage@Ipp:
10V
-
Operating Temperature:
-55°C~+125°C@(Tj)
-
Breakdown Voltage (VBR):
6.8V
-
Peak Pulse Power(Ppp)@8/20us:
-
-
Junction Capacitance(Cj)@1MHz:
21pF@1MHz
-
Reverse Stand-Off Voltage (Vrwm):
5.5V
-
Package:
X4-DFN-2
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Active
-
Type:
Zener
-
Bidirectional Channels:
1
-
Voltage - Reverse Standoff (Typ):
5.5V (Max)
-
Voltage - Breakdown (Min):
6.8V (Typ)
-
Voltage - Clamping (Max) @ Ipp:
10V
-
Current - Peak Pulse (10/1000µs):
12.5A (8/20µs)
-
Power - Peak Pulse:
-
-
Power Line Protection:
No
-
Applications:
General Purpose
-
Capacitance @ Frequency:
21pF @ 1MHz
-
Mounting Type:
Surface Mount
-
Package / Case:
01005 (0402 Metric)
-
Supplier Device Package:
2-X4DFN (0.45x0.24)
-
Base Part Number:
ESDM1
-
detail:
10V Clamp 12.5A (8/20µs) Ipp Tvs Diode Surface Mount 2-X4DFN (0.45x0.24)
