NSR05402 دیتاشیت

NSR05402

مشخصات دیتاشیت

نام دیتاشیت NSR05402
حجم فایل 275.626 کیلوبایت
نوع فایل pdf
تعداد صفحات 4

مشاهده دیتاشیت NSR05402

دانلود دیتاشیت

سایر مستندات

NSR05402NXT5G 5 pages

مشخصات فنی

  • RoHS: true
  • Category: Diodes/Schottky Barrier Diodes (SBD)
  • Datasheet: onsemi NSR05402NXT5G
  • Diode Configuration: Single
  • Reverse Voltage (Vr): 40V
  • Forward Voltage (Vf@If): 570mV@500mA
  • Reverse Leakage Current (Ir): 3uA@40V
  • Average Rectified Current (Io): 500mA
  • Package: DSN-2
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Diode Type: Schottky
  • Voltage - DC Reverse (Vr) (Max): 40V
  • Current - Average Rectified (Io): 500mA (DC)
  • Voltage - Forward (Vf) (Max) @ If: 620mV @ 500mA
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 20µA @ 40V
  • Capacitance @ Vr, F: 9.5pF @ 5V, 1MHz
  • Mounting Type: Surface Mount
  • Package / Case: SC-79, SOD-523
  • Supplier Device Package: SOD-523
  • Operating Temperature - Junction: -55°C ~ 150°C
  • Base Part Number: NSR054
  • detail: Diode Schottky 40V 500mA (DC) Surface Mount SOD-523
