SBAS21DW5T3G دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت SBAS21DW5T3G	دانلود دیتاشیت

RoHS: true
Category: Diodes/Switching Diode
Datasheet: onsemi SBAS21DW5T3G
Power Dissipation: 385mW
Diode Configuration: Single
Reverse Voltage (Vr): 250V
Operating Temperature: -55°C~+150°C@(Tj)
Forward Voltage (Vf@If): 1.25V@200mA
Reverse Leakage Current: 100nA@200V
Reverse Recovery Time (trr): 50ns
Average Rectified Current (Io): 200mA
Package: SC-88A
Manufacturer: onsemi
Series: Automotive, AEC-Q101
Packaging: Tape & Reel (TR)
Part Status: Active
Diode Type: Standard
Voltage - DC Reverse (Vr) (Max): 250V
Current - Average Rectified (Io) (per Diode): 200mA (DC)
Voltage - Forward (Vf) (Max) @ If: 1.25V @ 200mA
Speed: Small Signal =< 200mA (Io), Any Speed
Current - Reverse Leakage @ Vr: 100nA @ 200V
Operating Temperature - Junction: -55°C ~ 150°C
Mounting Type: Surface Mount
Package / Case: 5-TSSOP, SC-70-5, SOT-353
Supplier Device Package: SC-88A (SC-70-5/SOT-353)
Base Part Number: SBAS21
detail: Diode Array 2 Independent Standard 250V 200mA (DC) Surface Mount 5-TSSOP, SC-70-5, SOT-353
