ESD5382MUT5G دیتاشیت

ESD5382MUT5G

مشخصات دیتاشیت

نام دیتاشیت ESD5382MUT5G
حجم فایل 79.407 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

دانلود دیتاشیت ESD5382MUT5G

دانلود دیتاشیت

سایر مستندات

ESD5381 Series 5 pages

ESD5382MUT5G 5 pages

مشخصات فنی

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
  • Datasheet: onsemi ESD5382MUT5G
  • Clamping Voltage@Ipp: 26V
  • Operating Temperature: -55°C~+150°C@(Tj)
  • Breakdown Voltage (VBR): 14.2V
  • Peak Pulse Power(Ppp)@8/20us: -
  • Junction Capacitance(Cj)@1MHz: -
  • Reverse Stand-Off Voltage (Vrwm): 3V
  • Package: X3-DFN-2
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Type: Zener
  • Unidirectional Channels: 1
  • Voltage - Reverse Standoff (Typ): 3V (Max)
  • Voltage - Breakdown (Min): 14.2V
  • Voltage - Clamping (Max) @ Ipp: 26V
  • Current - Peak Pulse (10/1000µs): 1A (8/20µs)
  • Power - Peak Pulse: -
  • Power Line Protection: No
  • Applications: General Purpose
  • Capacitance @ Frequency: -
  • Mounting Type: Surface Mount
  • Package / Case: 0201 (0603 Metric)
  • Supplier Device Package: 2-X3DFN (0.62x0.32)
  • Base Part Number: ESD53
  • detail: 26V Clamp 1A (8/20µs) Ipp Tvs Diode Surface Mount 2-X3DFN (0.62x0.32)
